2025 Honda CBR500R at Great Lakes Honda

Standard

• Displacement : 471 cc
• Bore & Stroke : 67 mm x 66.8 mm
• Compression Ratio : 10.7:1
• Fuel Delivery : PGM-FI electronic fuel injection with 34 mm throttle bodies
• Transmission : Six-speed
• Valve Train : DOHC, four valves per cylinder
• Engine Type : Liquid-cooled parallel twin
• Final Drive : 520 chain (15T/41T)

Standard

• ABS System : 2-channel
• Tires : Front: 120/70-17, Rear: 160/60-17
• Wheelbase : 1,410 mm (55.5 in.)
• Fuel Capacity : 17.1 litres
• Seat Height : 785 mm (30.9 in.)
• Colour : Grand Prix Red
• Brakes : Front: Twin four-piston calipers with 320 mm discs, Rear: 240 mm disc
• Curb Weight : 190 kg (419 lb) including required fluids and full tank of gas—ready to ride

Standard

• Front Suspension : 41 mm Showa SFF-BP (Separate Function- Big Piston front Fork) inverted fork; 108 mm (4.3 in) travel
• Rear Suspension : Pro-Link single shock with spring preload adjustability; 119 mm ( 4.7 in.) travel
